Intelligent Safety
PES three-level adjustment, multiple performance modes, allowing for flexible selection in complex working conditions;OPS protection;
Hydraulic pipe burst protection, forward tilt self-locking protection;
Multiple electrical protections (short circuit protection, overheat protection, low battery protection, sequential protection); parking safety reminder, slow roll-off warning on slopes.
Comfort and Energy Saving
Standard wide-angle rearview mirror;
Wide-view mast, providing a wider working field of vision and enhanced safety;
Load-sensitive multi-way valve, resulting in a more energy-efficient system and better micro-motion control; Standard USB power interface, mobile phone and cup holders for convenient phone charging; Standard semi-enclosed seat for improved driver comfort.
Stable and Efficient
Color screen instrument panel: Comprehensive vehicle information display, timely reminders, and convenient operation;
High-ratio parallel axle, independently developed, safe, reliable, compact structure, and powerful;
Large-angle steering axle, reducing turning radius;
The oil pump uses a synchronous reluctance motor for efficient lifting and steering at all speeds.
Easy Maintenance
By opening the seat cover and counterweight cover, components such as the pump/pump motor, electronic control, DC-DC converter, and integrated electrical box are clearly visible, making maintenance and upkeep convenient.
Performance parameters
| Model | Unit | CPD40 | CPD45 | CPD50 | – | ||||||
| Rated Lifting Capacity | kg | 4000 | 4500 | 5000 | – | ||||||
| Load Center Distance | mm | 500 | 500 | 500 | – | ||||||
| Standard Mast Lifting Height | mm | 3000 | 3000 | 3000 | – | ||||||
| Overall Length (without forks) | mm | 3250 | 3250 | 3250 | – | ||||||
| Overall Width | mm | 1545 | 1545 | 1545 | – | ||||||
| Grading Force, Full Load | % |
|
|
|
– | ||||||
| – | – | – | – | – | – |
